TIDC

Lacing

Pitch

Pin

Plate

Plate

Hole

Width Over

Average

Tensile

chain No.

Pattern

Diameter

Height

Thickness

Diameter

Bearing

Weight

Strength

No.

Pin

Per Meter

( P )

( d )

( H )

( T )

( D )

( A )

( Kgs )

( Kgf )

Max

Max

Max

Min

Max

Min

*O 061 22

2 x 2

6.31

0.24

1150

*O 061 23

2 x 3

7.63

0.30

1150

*O 061 34

3 x 4

10.27

0.41

1720

*O 061 44

4 x 4

9.525

3.28

8.20

1.25

3.29

11.59

0.47

2300

*O 061 46

4 x 6

14.23

0.59

2300

*O 061 66

6 x 6

16.87

0.71

3400

*DL 06 44 0004

4 x 4

9.525

3.28

8.20

1.00

3.29

10.13

0.44

2300

DL 07 23

2 x 3

12.27

0.71

1900

**DL 07 32

3 x 2

12.00

4.45

11.08

2.05

4.46

12.27

0.71

1900

DL 07 43

4 x 3

16.75

0.99

3000

DL 08 22 0001

2 x 2

9.20

0.39

1910

DL 08 23 0001

2 x 3

10.75

0.47

1910

DL 08 34 0001

3 x 4

14.25

0.66

2860

DL 08 44 0002

4 x 4

12.70

4.45

10.90

1.60

4.46

16.00

0.75

3810

DL 08 46 0001

4 x 6

1850

0.94

3810

DL 08 66 0003

6 x 6

2280

1.12

4420

DL 08 88 0001

8 x 8

30.00

1.49

7400

DL 10 43 00 01

4 x 3

15.875

5.08

13.59

1.61

5.12

15.35

0.89

3750

DL 10 64 00 01

6 x 4

19.50

1.26

5000

***DL 12 66 0002

6 x 6

19.05

5.72

16.10

1.90

5.73

26.30

1.93

9200

***DL 12 66 0003

6 x 6

DL 12 86 0001

8 x 6

19.05

5.72

13.94

1.76

5.75

28.65

2.06

8850

DL 12 88 0001

8 x 8

19.05

5.94

18.00

2.39

5.96

42.55

3.81

14500

DL 16 44 0001

4 x 4

25.40

9.53

24.10

4.09

9.56

44.77

5.14

17240

DL 16 66 0001

6 x 6

25.40

8.27

20.58

4.05

8.31

53.53

4.31

19000

DL 16 66 0002

6 x 6

25.40

8.28

21.00

3.10

8.31

41.90

4.20

24000

DL 16 66 0003

6 x 6

25.40

8.28

21.00

3.20

8.31

43.00

4.48

19900

DL 16 66 0005

6 x 6

25.40

8.27

20.58

4.05

8.31

44.77

4.31

19000

DL 16 87 0001

8 x 7

25.40

8.28

21.00

3.20

8.31

53.00

5.59

23200

DL 20 22

2 x 2

23.13

2.54

9500

DL 20 23

2 x 3

27.80

3.22

9500

DL 20 34

3 x 4

37.13

4.57

14200

DL 20 44

4 x 4

31.75

10.19

26.44

4.60

10.07

41.81

5.22

20000

DL 20 46

4 x 6

51.13

6.56

20000

DL 20 66

6 x 6

60.49

7.91

30500

DL 20 65 0001

6 x 5

31.75

9.53

25.09

3.23

9.43

40.40

5.06

14060

DL 20 67 0001

6 x 7

31.75

9.53

25.09

3.23

9.43

46.55

5.95

16870

DL 24 66 0001

6 x 6

38.10

14.63

33.42

5.20

14.49

70.40

11.47

52000
