Type 3 - With Bush, Without Roller
|
Diamond
Chain |
Pitch |
Width |
Roller |
Plate |
Pin |
Pin |
Pin |
Tensile |
|
No. |
|
between |
Dia |
Height |
Inner |
outer |
Length |
Strength |
| |
|
Inner |
|
|
Diameter |
Diameter |
|
|
| |
|
Plates |
|
|
|
|
|
|
| |
(P) |
(W) |
(D) |
(H) |
(d1) |
(d2) |
(A) |
Kgf |
| |
|
(Min) |
(Max) |
(Max) |
(Min) |
|
(Max) |
(Min) |
|
B 083 01 HP 01 |
12.70 |
7.75 |
8.51 |
11.80 |
4.50 |
6.28 |
17.20 |
950 |
|
B 101 01 HP 01 |
15.875 |
9.65 |
10.16 |
14.70 |
5.18 |
7.02 |
19.60 |
1300 |
|
B 102 01 HP 01 |
15.875 |
9.53 |
10.16 |
14.70 |
5.18 |
7.02 |
20.50 |
1850 |
|
B 120 01 HP 01 |
19.05 |
11.68 |
12.07 |
16.10 |
5.85 |
8.09 |
22.70 |
1300 |
Type 4 - Double Pitch Hollow Pin Chains
Small Roller Chains
|
Diamond
Chain |
Pitch |
Width |
Roller |
Plate |
Pin Inner |
Pin |
Pin |
Tensile |
|
No. |
|
between |
Dia |
Height |
Diameter |
outer |
Length |
Strength |
| |
|
Inner |
|
|
|
Diameter |
|
|
| |
|
Plates |
|
|
|
|
|
|
| |
(P) |
(W) |
(D) |
(H) |
(d1) |
(d2) |
(A) |
Kgf |
| |
|
(Min) |
(Max) |
(Max) |
(Min) |
|
(Max) |
(Min) |
|
A 102 01 HP 01 |
31.75 |
9.40 |
10.16 |
14.58 |
5.16 |
7.02 |
20.50 |
1630 |
|
A 121 01 HP 01 |
38.10 |
12.57 |
11.91 |
18.06 |
5.99 |
8.38 |
25.50 |
2310 |
