Automotive 'O' Ring Chains


Intl.

Diamond

Pitch

Width

Roller

IP

OP

IP

OP

Width

Bearing

Width

Tensile

Ref.

Chain

between

Diameter

Height

Height

Thickness

Thickness

Over

Pin

Over

Strength

No.

No.

Inner

Bearing

Diameter

Joint

Plates

Pin

Fasteners

Kgf

(P)

(W)

(D)

(H1)

(H2)

(T1)

(T2)

(A)

(d)

(B)

(Min)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Min)

J415 OR

D 087 01

12.70

5.15

7.75

10.57

10.57

1.37

1.37

15.10

4.07

16.24

1300

J428 OR

D 089 01

12.70

7.95

8.51

11.56

10.57

1.58

1.50

19.00

4.50

20.30

1845

J520 OR

D 105 01

15.875

6.35

10.16

14.48

13.51

2.00

2.00

20.57

5.07

22.04

2500

Other 'O' Ring Chains


Intl.

Diamond

Pitch

Width

Roller

IP

OP

IP

OP

Width

Bearing

Width

Tensile

Ref.

Chain

between

Diameter

Height

Height

Thickness

Thickness

Over

Pin

Over

Strength

No.

No.

Inner

Bearing

Diameter

Joint

Plates

Pin

Fasteners

(P)

(W)

(D)

(H1)

(H2)

(T1)

(T2)

(A)

(d)

(B)

Kgf

(Min)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Max)

(Min)

08B OR

D 083 01

12.70

7.75

8.51

11.56

10.57

1.58

1.50

19.00

4.45

20.30

1845

10B OR

D 101 01

15.875

9.65

10.16

14.48

13.51

1.58

1.58

21.94

5.06

23.53

2265
