Single Strand
|
Intl |
Diamond |
Pitch |
Width |
Roller |
Plate |
Plate |
Bearing |
Width |
Width |
Transverse |
Tensile |
| |
|
|
Between |
|
Pin |
Over |
Over |
Pitch |
Strength |
|
Ref. |
Chain |
|
|
Dia |
Height |
Thickness |
|
|
|
|
|
| |
|
|
Inner |
|
Dia |
Bearing |
Joining |
|
|
|
No. |
No. |
|
Plates |
|
IP |
OP |
IP |
OP |
|
Pin |
Fasteners |
|
|
| |
|
(P) |
(W) |
(D) |
H1 |
H2 |
T1 |
T2 |
(d) |
(A) |
(B) |
(P1) |
Kgf |
| |
|
|
(Min) |
(Max) |
(Max) |
(Max) |
|
|
(Max) |
(Max) |
(Max) |
|
(Min) |
|
35-1 |
B 06A 01 SS 01 |
9.525 |
4.68 |
5.08 |
8.65 |
7.48 |
1.25 |
1.25 |
3.59 |
12.18 |
13.18 |
- |
570 |
|
40-1 |
D 08A 01 SS 01 |
12.70 |
7.85 |
7.92 |
12.00 |
10.40 |
1.50 |
1.50 |
3.96 |
17.80 |
21.80 |
- |
1045 |
|
50-1 |
D 102 01 SS 01 |
15.875 |
9.40 |
10.16 |
15.00 |
13.00 |
2.00 |
2.00 |
5.08 |
21.80 |
25.90 |
- |
1710 |
|
60-1 |
D 121 01 SS 01 |
19.05 |
12.58 |
11.91 |
18.00 |
16.60 |
2.40 |
2.40 |
5.94 |
26.90 |
31.50 |
- |
2280 |
|
80-1 |
D 161 01 SS 01 |
25.40 |
15.75 |
15.88 |
24.10 |
20.80 |
3.00 |
3.00 |
7.92 |
33.50 |
38.90 |
- |
3700 |
Double Strand
|
40-2 |
D 08A 02 SS 01 |
12.70 |
7.85 |
7.92 |
12.00 |
10.40 |
1.50 |
1.50 |
3.96 |
32.30 |
36.20 |
14.38 |
2090 |
|
50-2 |
D 102 02 SS 01 |
15.875 |
9.40 |
10.16 |
15.00 |
13.00 |
2.00 |
2.00 |
5.08 |
37.90 |
44.00 |
18.11 |
3420 |
|
60-2 |
D 121 02 SS 01 |
19.05 |
12.58 |
11.91 |
18.00 |
16.60 |
2.40 |
2.40 |
5.94 |
49.80 |
54.40 |
22.78 |
4560 |
|
80-2 |
D 161 02 SS 01 |
25.40 |
15.75 |
15.88 |
24.10 |
20.80 |
3.00 |
3.00 |
7.92 |
62.70 |
68.10 |
29.29 |
7400 |
Triple Strand
|
40-3 |
D 08A 03 SS 01 |
12.70 |
7.85 |
7.92 |
12.00 |
10.40 |
1.50 |
1.50 |
3.96 |
45.30 |
49.20 |
14.38 |
3300 |
|
50-3 |
D 102 03 SS 01 |
15.875 |
9.40 |
10.16 |
15.00 |
13.00 |
2.00 |
2.00 |
5.08 |
56.80 |
60.90 |
18.11 |
5200 |
|
60-3 |
D 121 03 SS 01 |
19.05 |
12.58 |
11.91 |
18.00 |
16.60 |
2.40 |
2.40 |
5.94 |
72.60 |
77.20 |
22.78 |
7500 |
|
80-3 |
D 161 03 SS 01 |
25.40 |
15.75 |
15.88 |
24.10 |
20.80 |
3.00 |
3.00 |
7.92 |
91.90 |
97.10 |
29.29 |
12500 |
Note : Spares available for all models.
